4 Lane Instant Coffee Packaging Machine

This product is a fully automatic powder packaging machine, mainly used in industries such as medicine, health products, food, etc. The whole machine is made of SUS304 stainless steel, and the contact material part is made of SUS316, which meets GMP production standards. The whole machine is CE certified by the European Union, and the electrical configuration is CUL certified. All components that come into contact with the packaged material can be quickly disassembled and installed, making maintenance more convenient.

GET QUOTE

Parameter
Application
Advantage
Video

Machine Name	Powder Stick Packing Machine
Model	LC320B+P50-4/LC320BS+P50-4
No. of Lanes	4
Metering system	Custom long screws
Bags/Minute	20-80 cuts/min
Film roll width	Max.320mm
Film roll inner diameter	75mm
Film roll outer diameter	Max.400mm
Bag width	16-50mm
Bag length	40-160mm
Sealed type	Back seal/triple seal/Four-sided seal
Cut type	Fillet cut / flat cut / serrated cut
Power	220V 1P 50 or 60HZ/11KW
Air consumption	65-80L/min（0.6-0.8MPa）
Machine weight	about 700KG
Film material thickness	0.06-0.1 mm
Film material	OPP/CPP, OPP/PE, BOPP/VMPET/PE etc.
Optional	Anti-static device/Ribbon coding machine/Vacuum feeding machine/ laser marking machine/Finished product conveyor/Screw air compressor

The fully automatic powder packaging machine is widely used in the automatic packaging of loose powder products in industries such as medicine and health food, such as (pharmaceutical) powder, probiotics, protein powder, meal substitute powder, spirulina powder, instant coffee powder, lotus root powder, tea powder, pearl powder, seasoning, etc.

1.Efficient fingerprint prevention,the device is easy to clean

2.Automatic recognition system for broken or missing film,automatic alarm shutdown, film rolling correction docking device

3.Customized screw,the screw is customized according to the material mesh, fluidity, and sugar content.

4.Automatic correction: integral film frame, supply film tension control system to ensure stable bag making

5.System configuration: Adopting programmable bus system+bus servo, fast response and more accurate

6.Color control: Using color sensors to capture the color dots on the packaging film, ensuring the integrity of the pattern

7.More convenient maintenance: All components that come into contact with the packaged material can be quickly disassembled and installed.

8.Applicable to digital factories: In response to the trend requirements of Industry 4.0, it can be connected to SCADA and MES systems

9.12 common operating languages: easy to operate, with device fault prompts and self diagnostic functions

10.Safety and certification: Compliant with GMP production standards, EU CE certification for the entire machine, CUL certification for electrical configuration

11.Vertical sealing feature: The vertical 45 ° sealing device has a good vertical sealing effect and can be opened from the middle to both sides for easy maintenance.

12.Temperature control method: Bus type temperature module with independent temperature control, temperature display and setting are operated within the touch screen
